SKU: ESAH-1280-GT0

ATTO ExpressSAS H-1280GT

PCIe 4.0 HBA with eight external 12 Gbit/s SAS/SATA ports in low profile

Manufacturer:

Specifications

x8 PCI Express 4.0 host interface (backward compatible with x8 PCI Express 3.0)
Advanced Data Streaming (ADS) technology
8 external ports, SFF-8644 2x miniSAS HD (x4)
Backward compatible with 3/6 Gbit/s SAS/SATA
Advanced utilities ConfigTool and vConfigTool
Drivers for Windows, Linux (SUSE, Red Hat, Cent OS, Fedora), VMware, FreeBSD, illumos and macOS

ExpressSAS SAS/SATA host bus adapters (HBAs) from ATTO provide powerful backup for directly attached SAS and SATA storage. They are ideal for increased connectivity and maximum performance in data centers. The HBAs are available with a wide range of 8- and 16-port options. So administrators can always find the right card for their rack-mounted servers and workstations in data centers, data warehousing, video-on-demand and all other high-availability applications.

ExpressSAS HBAs are equipped with ATTO PowerCenter Pro, which offers hardware RAID capabilities for the price of a host bus adapter. It even manages to do so without additional drivers or a complicated setup. This makes PowerCenter Pro one of the most effective ways to improve performance while protecting data.

The ExpressSAS H1280GT model uses PCIe 4.0 host interconnect and has 8 external 12 Gbps ports with miniSAS-HD connector (SFF-8644). It is designed specifically for enterprise customers. With extensive testing and qualifications, the HBAs work flawlessly in transactional environments such as banking and finance, business intelligence, cloud computing and database applications.
