SKU: NA341TB3
Netstor NA341TB3
Expanding storage density via Thunderbolt 3
Manufacturer:
Netstor
1
- 8 lockable drive bays
- Thunderbolt 3 (2-way for daisy chaining)
- RAID-on-chip processor
- Accommodates SFF and LFF disks
The 2U rackmount provides large capacities via Thunderbolt 3. Thus, the storage of a workstation can be quickly expanded by 8 SAS/SATA drives. With Thunderbolt, the connection between host and JBOD with 40 Gbit/s is high-performance and uncomplicated. The NA341TB3 from Netstor offers additional security with an integrated temperature and fan monitoring system. It immediately reports high temperatures or the failure of one of the fans.
Similar products
Specifications
Dimensions and Weight
FormFactor
2 HE Rackmount
Administration
Dedicated Management Port
No
Serial port
No
General
Manufacturer
Netstor
RAID levels suppored
1
10(1E)
3
30
5
50
6
60
Single Disk or JBOD
10(1E)
3
30
5
50
6
60
Single Disk or JBOD
Model
Netstor RAID Systeme
Other Technical Features
RAID levels suppored
1
10(1E)
3
30
5
50
6
60
Single Disk or JBOD
10(1E)
3
30
5
50
6
60
Single Disk or JBOD
RAID controller
Single
Scale-Out architecture
No
Drives (max.)
8
Memory per controller
Memory capacity (fully populated)
1 GIGABYTE
Drive bays
2.5" compatible
Yes
Drive bays 3.5" (hotswap)
8
Enclosure backplane
Backplane (bandwidth)
SAS
Host connectors per controller
Onboard Host Interfaces (per controller)
1x 40Gbit/s Thundebolt 3
Public Cloud Gateway
Public Cloud Gateway
No
Supported protocols
Protocols supported (Block)
Thunderbolt 3
Protocols supported (File)
N/A
Protocols supported (Object)
-
