SKU: ESEV-7016GL1
Infortrend EonServ EV7016GL1
High-performance storage servers for the enterprise sector
Manufacturer:
Discontinued
Dieses Produkt ist aktuell nicht mehr verfügbar.
- Data protected by Infortrend RAID technology
- SANWatch is intuitive and easy to use
- Expandable to 436 HDDs via SAS expansion port with JBODs
- Easy maintenance with modular components
High-performance enterprise storage servers from the EonServ 7000 series offer Infortrend's new generation of hybrid storage servers with their fast processors. They combine the best of both worlds: High server performance with the reliability of RAID systems. This is accompanied by large capacities, high availability, easy maintenance and simple management. Models from the EV-7016GL1 line occupy 3U in the rack and accommodate 16 SFF/LFF drives.
Similar products
Specifications
Drive bays
Drive bays 3.5" (hotswap)
16
2.5" compatible
Yes
Power supply
installed
2
Other Technical Features
Drives (max.)
436
RAID levels suppored
0, 1, 5, 6, 10, 50, 60
Administration
Dedicated Management Port
No
Serial port
No
Memory
Memory (installed)
16 Gigabyte (GB)
Memory capacity (fully populated)
512
Processor
Processor Manufacturer
Intel
Processor model
Intel® Xeon E5-2609
Rack mount rails
Quick release rails
No
Dimensions and Weight
FormFactor
3 HE Rackmount
General
RAID levels suppored
0, 1, 5, 6, 10, 50, 60
Model
EonServ 7000
Expansion and connectivity
PCIe Slots total (CPU1/CPU2)
1x PCIe 3.0 x16, 1x PCIe 3.0 x8
USB 3.0 Ports (front/rear/internal)
2
USB 2.0 Ports (front/rear/internal)
2
Network
Networking (type)
2x 10Gbit/s iSCSI SFP+
4x 1Gbit/s iSCSI RJ45
4x 1Gbit/s iSCSI RJ45
Video Surveillance
Cameras (max.)
570x 3MP Kamera
