SKU: NS370S
Netstor NS370S
SAS throughput in Netstor 1U JBOD
Manufacturer:
1
- 4 lockable drive bays
- Docks two servers at up to 2400 MB/s
- Accommodates SFF and LFF disks
- Many monitoring features
The 1U rackmount provides additional capacity via its 4 SAS/SATA drives. Thus, it enables space-saving storage expansion for docked servers and workstations. The connection between host and JBOD is quick and easy via the external Mini-SAS connection (SFF8088). All that is needed is a RAID controller, which can come from Areca, Broadcom, Microsemi or Highpoint. The Netstor storage offers additional security with an integrated temperature and fan monitoring system. It immediately reports high temperatures or the failure of one of the fans.
Similar products
Specifications
Drive bays
Drive bays 3.5" (hotswap)
4
2.5" compatible
Yes
Power supply
installed
1
Rack mount rails
Quick release rails
No
Dimensions and Weight
FormFactor
1 HE Rackmount
General
Model
JBOD ohne SAS Expander
Expansion and connectivity
External connections
1x 6Gbit/s miniSAS (SFF-8088)
Enclosure backplane
Backplane (bandwidth)
3Gbit/s SAS
Backplane (Type)
Discrete
