SKU: SCS-RS700AE13RS12U
ASUS RS700A-E13-RS12U
1U Dual-Socket Server with AMD EPYC 9005 CPUs, 12 tri-mode storage bays (NVMe/SATA/SAS), 2 PCIe 5.0 slots and 2 OCP 3.0
Manufacturer:
Asus
1
- Dual-Socket AMD EPYC 9005 Processors (SP5 LGA 6096, up to 400W TDP)
- Support for up to 24 DDR5 DIMMs (12 per CPU, up to 3072GB, 6400/5600 MHz)
- Up to 12 hot-swap NVMe/SATA/SAS drives (2.5") + 2x M.2 PCIe 3.0 x4 + microSD
- 4 expansion slots: 2x PCIe 5.0 x16 (FHHL) + 2x OCP 3.0 PCIe 5.0 x16
- 1+1 redundant 2000W 80PLUS Platinum power supplies
- Integrated ASMB12-iKVM for remote management
This ASUS server targets performance-intensive applications where high computing power, large data volumes, and scalable infrastructure are crucial. Primary markets include High Performance Computing (HPC), AI-based forecasting and analytics workloads, terabyte-scale data warehouse applications, and demanding virtualization environments. The storage and expansion concept features up to twelve hot-swap tri-mode drives (NVMe/SATA/SAS, 2.5") and four PCIe 5.0 expansion slots (2x PCIe Gen5 x16 FHHL + 2x OCP 3.0 Gen5 x16) for high bandwidth and future-proof scalability. Networking includes a dedicated management LAN port (ASMB12-iKVM) and flexible OCP options. Cooling uses eight 40x56mm case fans, optimized for dual AMD EPYC 9005 processors with up to 400W TDP and 192 Zen 5 cores.
Similar products
Application Server
Zealbox Z70-12R2
Individual and customised enterprise-class servers
Show product
Application Server
Zealbox Z70-24R2
Individual and customised enterprise-class servers
Show product
Application Server
Zealbox Z70-36R4
Individual and customised enterprise-class servers
Show product
Application Server
Zealbox Z70-08T
Individual and customized enterprise-class servers with Intel CPUs
Show product
Application Server
Zealbox Z50.17-36R4
Individual and customised enterprise-class servers
Show product
Application Server
Zealbox Z70-16R3
Individual and customised enterprise-class servers
Show product
Application Server
Zealbox Z70-24R4
Individual and customised enterprise-class servers
Show product
Application Server
Zealbox Z80-08R2
Individual and customized enterprise-class servers with AMD CPUs
Show product
Application Server
Zealbox Z80-12R2
Individual and customized enterprise-class servers with AMD CPUs
Show product
Application Server
Zealbox Z80-16R3
Individual and customized enterprise-class servers with AMD CPUs
Show product
Application Server
Zealbox Z80-24R2
Individual and customized enterprise-class servers with AMD CPUs
Show product
Application Server
Zealbox Z80-24R4
Individual and customized enterprise-class servers with AMD CPUs
Show product
Application Server
Zealbox Z80-36R4
Individual and customized enterprise-class servers with AMD CPUs
Show product
Application Server
Zealbox Z50.16-24R4
Individual and customised enterprise-class servers
Show product
Specifications
Dimensions and Weight
Width
483 Millimeter (mm)
Depth
821.7 Millimeter (mm)
Height
43.2 Millimeter (mm)
Weight
17 Kilogram (kg)
FormFactor
1 HE Rackmount
Administration
Dedicated Management Port
Yes
Management Controller
Aspeed AST2600
General
Manufacturer
Asus
PCIe Generation
5.0
Model
RS700A-E13-RS12U
Memory
Memory modules (type)
RDIMM
Memory modules (max.)
24
Memory channels per CPU
12
Memory capacity (fully populated)
3TB
Drive bays
Drive bays 2.5" (hotswap)
12
Expansion and connectivity
PCIe Slots total (CPU1/CPU2)
2 + 2 OCP3.0
USB 3.0 Ports (front/rear/internal)
0/2/0
PCIe x16 Slots (CPU1/CPU2)
2 + 2 OCP3.0
Warranty and service
Optional services
5 Jahre Vor-Ort-Service 24/7
Vollwartungsvertrag BASIC für 5 Jahre ab Lieferung
3 Jahre Vorabaustausch-Service
5 Jahre Vorabaustausch-Service
3 Jahre Vor-Ort-Service NBD
5 Jahre Vor-Ort-Service NBD
3 Jahre Vor-Ort-Service 24/7
Vollwartungsvertrag BASIC für 5 Jahre ab Lieferung
3 Jahre Vorabaustausch-Service
5 Jahre Vorabaustausch-Service
3 Jahre Vor-Ort-Service NBD
5 Jahre Vor-Ort-Service NBD
3 Jahre Vor-Ort-Service 24/7
Other services
Kundenimage Vorinstallation
BIOS-Konfiguration nach Kundenwunsch
Festplattenpartitionierung nach Kundenwunsch
Individuelle Systemkonfiguration
BIOS-Konfiguration nach Kundenwunsch
Festplattenpartitionierung nach Kundenwunsch
Individuelle Systemkonfiguration
Service package
Vollwartungsvertrag BASIC für 3 Jahre ab Lieferung
Network
Networking (type)
Kein onboard Netzwerk
Processor
Processor Manufacturer
AMD
Processor type
AMD EPYC™ 9004 (Genoa) Prozessor
AMD EPYC™ 9005 (Turin) Prozessor
AMD EPYC™ 9005 (Turin) Prozessor
Processors (max.)
2
Processor socket
LGA 6096
Power supply
installed
2
80PLUS certification
Titanium
Required voltage
Wechselstrom 110/230 V (50/60 Hz)
Power supply
2000W Netzteil
Operating Environment
Operating Temperature (min.)
10 Celsius (°C)
Operating Temperature (max.)
35 Celsius (°C)
Chip
Mainboard
K15PP-D24
Chipset
SoC
Graphics
Graphics (type)
AST26000
Rack mount rails
Rail type
Teleskopschienen
