SKU: SCS-RS720AE13RS12U
ASUS RS720A-E13-RS12U
2U Dual-Socket Server with AMD EPYC 9005 CPUs,12 NVMe/SATA/SAS bays, 10 PCIe 5.0 slots and 2 OCP 3.0
Manufacturer:
Asus
1
- Powered by Dual-Socket AMD EPYC™ 9005 Processors (SP5 LGA 6096P, up to 400W TDP)
- Support for up to 24 DDR5 RDIMM/3DS RDIMM (12 per CPU, up to 3072GB per socket, 6400/5600 MHz)
- Up to 12 hot-swap NVMe/SATA drives (8x 3.5"/2.5" + 4x 2.5") + 2x M.2 PCIe 3.0 x4 + microSD
- 10 expansion slots: 6x PCIe Gen5 x8/3x x16 (FHFL) + 2x PCIe Gen5 x16 (FHHL) + 2x OCP 3.0 Gen5 x16
- 1+1 redundant 2700W 80PLUS Titanium power supplies
- Integrated ASMB12-iKVM with Realtek RTL8211F management LAN
This ASUS server targets performance-intensive applications where high computing power, large data volumes, and scalable infrastructure are crucial. Primary markets include High Performance Computing (HPC), AI-based forecasting and analytics workloads, terabyte-scale data warehouse applications, and demanding virtualization environments. The storage and expansion concept features up to twelve hot-swap NVMe/SATA/SAS drives (8x 3.5"/2.5" + 4x 2.5") and ten PCIe 5.0 slots (6x Gen5 x8/3x x16 FHFL + 2x Gen5 x16 FHHL + 2x OCP 3.0 Gen5 x16) for high bandwidth and future-proof expansions. Networking includes a dedicated Realtek RTL8211F management LAN port (ASMB12-iKVM) and flexible OCP options. Cooling uses six mid-case fans with optimized airflow channels, designed for dual AMD EPYC 9005 processors up to 400W TDP.
Similar products
Application Server
Zealbox Z70-12R2
Individual and customised enterprise-class servers
Show product
Application Server
Zealbox Z70-24R2
Individual and customised enterprise-class servers
Show product
Application Server
Zealbox Z70-36R4
Individual and customised enterprise-class servers
Show product
Application Server
Zealbox Z70-08T
Individual and customized enterprise-class servers with Intel CPUs
Show product
Application Server
Zealbox Z50.17-36R4
Individual and customised enterprise-class servers
Show product
Application Server
Zealbox Z70-16R3
Individual and customised enterprise-class servers
Show product
Application Server
Zealbox Z70-24R4
Individual and customised enterprise-class servers
Show product
Application Server
Zealbox Z80-08R2
Individual and customized enterprise-class servers with AMD CPUs
Show product
Application Server
Zealbox Z80-12R2
Individual and customized enterprise-class servers with AMD CPUs
Show product
Application Server
Zealbox Z80-16R3
Individual and customized enterprise-class servers with AMD CPUs
Show product
Application Server
Zealbox Z80-24R2
Individual and customized enterprise-class servers with AMD CPUs
Show product
Application Server
Zealbox Z80-24R4
Individual and customized enterprise-class servers with AMD CPUs
Show product
Application Server
Zealbox Z80-36R4
Individual and customized enterprise-class servers with AMD CPUs
Show product
Application Server
Zealbox Z50.16-24R4
Individual and customised enterprise-class servers
Show product
Specifications
Dimensions and Weight
Width
484.65 Millimeter (mm)
Depth
822.16 Millimeter (mm)
Height
87.3 Millimeter (mm)
Weight
22 Kilogram (kg)
FormFactor
2 HE Rackmount
Administration
Dedicated Management Port
Yes
Management Controller
Aspeed AST2600
General
Manufacturer
Asus
PCIe Generation
5.0
Model
RS720A-E13-RS12U
Memory
Memory modules (type)
RDIMM
Memory modules (max.)
1
Memory channels per CPU
12
Memory capacity (fully populated)
3TB
Drive bays
2.5" compatible
Yes
Drive bays 3.5" (hotswap)
12
Expansion and connectivity
PCIe Slots total (CPU1/CPU2)
8 + 2 OCP3.0
USB 3.0 Ports (front/rear/internal)
2/2/0
PCIe x8 Slots (CPU1/CPU2)
6
PCIe x16 Slots (CPU1/CPU2)
7 (2 OCP3.0)
Warranty and service
Optional services
Vollwartungsvertrag BASIC für 5 Jahre ab Lieferung
3 Jahre Vorabaustausch-Service
5 Jahre Vorabaustausch-Service
3 Jahre Vor-Ort-Service NBD
5 Jahre Vor-Ort-Service NBD
3 Jahre Vor-Ort-Service 24/7
5 Jahre Vor-Ort-Service 24/7
3 Jahre Vorabaustausch-Service
5 Jahre Vorabaustausch-Service
3 Jahre Vor-Ort-Service NBD
5 Jahre Vor-Ort-Service NBD
3 Jahre Vor-Ort-Service 24/7
5 Jahre Vor-Ort-Service 24/7
Other services
Kundenimage Vorinstallation
BIOS-Konfiguration nach Kundenwunsch
Festplattenpartitionierung nach Kundenwunsch
Individuelle Systemkonfiguration
BIOS-Konfiguration nach Kundenwunsch
Festplattenpartitionierung nach Kundenwunsch
Individuelle Systemkonfiguration
Service package
Vollwartungsvertrag BASIC für 3 Jahre ab Lieferung
Network
Networking (type)
Kein onboard Netzwerk
Processor
Processor Manufacturer
AMD
Processor type
AMD EPYC™ 9004 (Genoa) Prozessor
AMD EPYC™ 9005 (Turin) Prozessor
AMD EPYC™ 9005 (Turin) Prozessor
Processors (max.)
2
Processor socket
LGA 6096
Power supply
installed
2
80PLUS certification
Titanium
Required voltage
Wechselstrom 110/230 V (50/60 Hz)
Power supply
2700W Netzteil
Operating Environment
Operating Temperature (min.)
10 Celsius (°C)
Operating Temperature (max.)
35 Celsius (°C)
Chip
Mainboard
K15PP-D24
Chipset
SoC
Graphics
Graphics (type)
AST26000
Rack mount rails
Rail type
Teleskopschienen
